Triple Offset Butterfly Valve
XURI is a triple offset butterfly valve manufacturer specializing in high-temperature, high-pressure, and zero-leakage applications for power plants, oil and gas facilities, and industrial process systems.
The triple offset design creates a non-rubbing metal sealing system, eliminating seat deformation and jamming caused by severe thermal cycling. Our NPS 20 Class 900 high-temp version was awarded the Gold Medal at the International Valve Expo for zero-leakage performance in severe power station service.
Engineering Advantages:
- Patented multi-level metal sealing structure
- Zero-leakage performance in severe service
- Excellent thermal cycling resistance
- Low operating torque with non-rubbing closure
- Available with hydraulic/pneumatic quick-close actuators
- Sizes from DN50 to DN3000
Typical Applications
- High-temperature flue gas isolation
- Steam turbine bypass isolation
- Hot air duct isolation dampers
- Fired heater flue gas service
- Waste heat recovery isolation
Technical Specifications
| Design Standard | API 609 Category B / ASME B16.34 |
| Pressure Class | Class 150 - Class 900 |
| Size Range | DN50 - DN3000 (2" - 120") |
| Body Materials | WCB, WC6, WC9, CF8, CF8M, Duplex |
| Seat Design | Metal-to-metal (triple offset) |
| Temperature Range | Up to 800 degC |
| End Connections | Wafer, Lug, Flanged, Butt-weld |
| Operation | Manual, Gearbox, Pneumatic, Hydraulic, Electric |
Standards & Certifications
- API 609 Category B - Triple offset design
- API 598 - Shell and seat testing
- ISO 9001 - Quality management
- International Valve Expo Gold Medal award
Why Choose XURI
Manufacturing Capability
XURI operates professional valve manufacturing facilities with in-house casting capability and an annual production capacity of 6,000 tons.
Quality Assurance
Complete inspection process including PMI, NDT, hydrostatic testing, and dimensional inspection ensures product reliability.
Engineering Experience
Supporting severe service applications including power generation, oil and gas, chemical, and energy projects worldwide.
Global Supply
Products supplied to EPC contractors, distributors, and industrial projects across 30+ countries, with factory-direct pricing and on-time delivery.
FAQ
What is the advantage of a triple offset butterfly valve?
The triple offset design eliminates seat rubbing during operation, providing zero-leakage metal sealing and long service life in high-temperature applications.
What temperature range can XURI triple offset valves handle?
XURI triple offset butterfly valves are suitable for temperatures up to 800 degC, making them ideal for power plant and high-temperature process applications.
How large can XURI triple offset butterfly valves be supplied?
XURI can supply triple offset butterfly valves up to DN3000 (120 inches) for large-diameter applications.
