12 Inch Gate Valve

Product Introduction

Product Description

The 12 inch gate valve can also be called 300mm gate valve or gate valve dn300, which is often used in boiler installations and steam services, and is a very common gate valve size.

12 inch gate valve controls the media’s flow by lifting the gate (open) and lowering the gate (closed). A gate valve’s distinct feature is the straight-through unobstructed passageway, which induces minimal pressure loss over the valve. The unobstructed bore of a gate valve also allows for a pig’s passage in cleaning pipe procedures, unlike butterfly valves. Gate valves are available in many options, including various sizes, materials, temperature and pressure ratings, and gate and bonnet designs.

12 inch gate valve description

-Design and manufacturing standards, in accordance with the: ASME B16.34, API6D;

-Structure length according to: ASME B16.10;

-The flange end size according to: ASME B16.5

-Threaded end size in accordance with the: ANSI B1.20.1;

-The butt end size in accordance with the: ANSI B16.25

-Socket size in accordance with the: ANSI B16.11

-Inspection and testing in accordance with the: API598

-An optional sealing surface material:13 cr alloy steel (code H)Carbide STL code (Y)Can choose other special sealing materials according to customer’s requirement.

-The main alternative material of 12 inch gate valve:

Carbon steel class: WCB, WCC, A105, etc

Class: stainless steel 304, 316, 304 L, 316 L, CF8, CF8M, CF3, CF3M, CF8C and duplex stainless steel, etc.

Class: low-temperature steel LF2, LCC, LCB, etc

Chrome molybdenum steel types: WC5 WC6, WC9, C5, etc

Advantages of DN300 Gate valve

Easy to maintain and disassemble

Optimal as a shut off valve

Bidirectional

Low cost

Can be used with slurries and viscous liquids

Available in large sizes

Inherently fire-safe (when used with a metal sheet)

Disadvantages of DN 300 Gate valve

Slow open and close time

Low-pressure limitations

Erosion of the seat and disk can occur

Poor throttling characteristics

Difficult to repair

Distributor of Metal Seated Wedge Gate Valve, View Gate Valve Weights Chart

Why Choose Us？

The company strictly implements industry and international standards, and develops and manufactures high-temperature and high-pressure gate valves, ball valves, globe valves, suction check valves and other on-off valves, high-pressure three-way valves, high and low pressure bypass valves, regulating valves, butterfly valves and other control valves. There are more than 1000 kinds of valve series products, which are widely used in thermal power, petrochemical, nuclear power, metallurgy, water conservancy and other industries, and provide many high-parameter valves for many special industries in China. , one of the suppliers of Qinshan Nuclear Power Plant; can design and manufacture various personalized valve products according to American ANSI, ASME, API standards, Japanese JIS, E101 standards, and British BS standards, and is committed to providing professional, accurate and professional valves to new and old customers around the world. , High-level products and services; product sales cover the whole country and are exported to more than 20 countries and regions such as Asia, Africa, Europe and the United States.
